Series 3000 Architectural Fixed Windows
About Series 3000 Architectural Fixed Windows
The Series 3000 Fixed Window system by Sol-A-Trol is a premier monumental solution designed to meet the most rigorous structural requirements of the Florida market. These fixed units are engineered to provide expansive clear sightlines while maintaining superior resistance to environmental forces, making them an ideal choice for high-end commercial and residential architectural projects.
Crafted from high-grade 6063-T6 extruded aluminum alloy, the Series 3000 features a robust 2-inch frame depth with a minimum wall thickness of 1/8-inch. This heavy-duty construction ensures exceptional stability and longevity. The frame members are expertly joined using a double mortise, tenon, and riveted assembly, providing a high degree of structural integrity and a clean, professional finish.
Specifically optimized for the South Florida High-Velocity Hurricane Zone (HVHZ), this system is available in a large missile impact-resistant model. It has been rigorously tested in accordance with Miami-Dade County protocols to withstand extreme design pressures of up to +/- 100 psf. Architects can select from a variety of premium finishes, including Kynar 500 and Bronze Hardcoat, to achieve the desired aesthetic while ensuring the system stands up to coastal environments.
Key Features
- Meets or exceeds AAMA specifications for HC-60 performance grade.
- Heavy-duty 2-inch frame depth with 1/8-inch wall thickness for maximum structural performance.
- Impact-resistant models available and tested for High-Velocity Hurricane Zones (HVHZ).
- Certified to withstand extreme design pressures of up to +/- 100 psf.
- Structural frame members joined by double mortise, tenon, and riveted construction.
- Glazing options accommodate 7/16-inch or 9/16-inch laminated glass for impact protection.
- Secure snap-in type glazing bead system for clean lines and reliable glass retention.
