Series 3000 Casement Windows
About SERIES 3000 Casement Windows
The Series 3000 Casement Window system represents the pinnacle of structural reliability and architectural versatility for the Florida B2B market. Designed by Sol-A-Trol to meet the rigorous demands of architectural installations, this system provides a robust solution for architects and developers seeking a balance between expansive views and uncompromising safety. Whether specified for high-end residential projects or commercial developments, the Series 3000 delivers consistent performance in the most challenging coastal environments.
Built from premium 6063-T6 extruded aluminum, the system features a 2-inch deep frame and sash with a minimum wall thickness of 1/8-inch for enhanced structural rigidity. The construction utilizes double mortise, tenon, and riveted joinery for the frames, while the sash vents are mitered, reinforced, and welded to ensure a factory-sealed, airtight perimeter. To maintain long-term durability against the elements, every contact point between the sash and frame is protected by high-grade neoprene weatherstripping.
Architecturally, the Series 3000 offers significant design flexibility, supporting single vent, dual vent, and various side-by-side or top-and-bottom combinations using integral imposts and mullions. Designers can choose from a range of high-performance finishes—including Kynar 500, bronze hardcoat, and baked enamel—to align with any project aesthetic. Ideal for High-Velocity Hurricane Zone (HVHZ) applications, this system is a proven choice for projects requiring maximum design pressure ratings and large missile impact resistance.
Key Features
- High-strength 6063-T6 extruded aluminum alloy for superior structural integrity.
- Heavy-duty 2-inch frame and sash depth with 1/8-inch minimum wall thickness.
- Florida Building Code approved for use in High-Velocity Hurricane Zones (HVHZ).
- Large missile impact resistant models tested to design pressures of +/- 100 PSF.
- Advanced glazing compatibility supporting 7/16-inch to 1-5/16-inch laminated and insulated glass.
- Professional hardware options including 5-knuckle butt hinges, 4-bar stainless steel mechanisms, and roto operators.
- Comprehensive weather sealing with neoprene weatherstripping at all contact points.
