Series 3062 Architectural Projected Windows
About Series 3062 Architectural Projected Windows
The Series 3062 Architectural Projected Window system by Sol-A-Trol is engineered for architectural excellence in the most demanding environments. These windows are specifically designed to provide reliable ventilation and exceptional structural integrity for commercial and monumental-scale projects. Built to meet or exceed AAMA specifications for HC-60, the Series 3062 is a heavy-duty solution that balances high-performance engineering with clean architectural lines.
Constructed from premium extruded 6063-T5 aluminum alloy, the system features a 2-inch frame depth with a minimum wall thickness of 1/8-inch for the frame and 1/16-inch for the tubular sash. The structural assembly utilizes double mortise, tenon, and riveted joints for the frame, while the vents are mitered, reinforced, and welded to ensure long-term stability and a factory seal. Comprehensive neoprene weatherstripping at all contact points ensures a tight seal against air and moisture.
To meet the stringent safety requirements of the Florida market, the Series 3062 is available in a large missile impact-resistant model. This configuration is tested in accordance with Miami-Dade County protocols to withstand design pressures of +/- 80 psf, providing essential protection for High-Velocity Hurricane Zones (HVHZ). Architects can further customize the system with various high-performance finishes, including Kynar 500, to ensure lasting aesthetic appeal.
Key Features
- Meets or exceeds AAMA specifications for HC-60 monumental windows.
- Heavy-duty 2-inch frame depth with 1/8-inch minimum wall thickness for enhanced structural performance.
- Impact-resistant models tested to Miami-Dade protocols for design pressures of +/- 80 psf.
- Durable double mortise, tenon, and riveted frame construction with mitered and welded sash vents.
- Standard high-quality white bronze locking hardware with a U.S. 25-D finish.
- Equipped with heavy-duty, non-magnetic stainless steel 4-bar adjustable friction hinges.
- Flexible glazing options for impact models supporting 7/16-inch, 9/16-inch, or 1-5/16-inch laminated glass.
