Series 5000 Impact Window Wall

ABOUT SERIES 5000 IMPACT WINDOW WALL

The Series 5000 Window Wall is a Architectural aluminum system engineered to deliver expansive, uninterrupted views while meeting the most demanding structural and environmental requirements. Designed for both impact and non-impact applications, this system is designed to receive Casement, Projected, Single Hung windows and Doors as well as a Sol-A-Shield, an aluminum clad composite panel which creates versatile solution for residential and commercial projects where strength, durability, and aesthetics are critical.

Built from 6063-T6 extruded aluminum, the Series 5000 features robust 5-inch deep tubular framing with reinforced structural integrity to withstand specified wind loads. Its precision-engineered construction ensures long-term performance, while maintaining a clean, modern appearance with flush interior glazing beads.

We can provide in a wide range of glazing options, including laminated impact glass, insulated configurations, any available low-e coatings from the biggest suppliers in the industry and the Aluminum Clad composite panel, which can be provided in a variety of architectural finishes—including clear anodized in both 4 and 7 mils, bronze hard coat, and electrostatically applied coatings in compliance with AAMA 2605 in both standard and any custom color can be matched  allowing for enhanced energy efficiency, sound control, and protection in hurricane-prone regions. Whether specified for large missile impact compliance or standard non-impact applications, the Series 5000 can be designed to the needs of the project design.

Available in a variety of architectural finishes including clear anodized in both 4 and 7 mils, bronze hard coat, and electrostatically applied coatings in compliance with AAMA 2605 in both standard and any custom color can be matched, the Series 5000 Window Wall offers design flexibility to complement any architectural style.

Ideal for creating continuous glass facades, this system combines structural strength with refined aesthetics, making it a reliable choice for projects that demand both performance and visual impact.

‍

‍

SERIES 5000 - KEY FEATURES

• Heavy-duty 5” deep aluminum framing for enhanced structural performance
• Impact and non-impact configurations available
• Designed and tested with laminated, insulated glass systems
• Designed and tested to receive an aluminum clad composite panel, available in any architectural finish
• Heavy wall design to receive operable windows, doors, and louvers.
• Engineered to meet or exceed Florida Building Code (FBC) requirements
• Flush interior glazing for a clean, modern finish
